Specialized strapping systems engineered to maintain rigid stability for glass, plastic and can pallet loads.
Reliable Strapping Solutions for Rigid Container Applications
Samuel Packaging Systems Group has specially designed the SBC-932 for rigid container applications. The side seal strapping system is engineered to provide consistent, retained strap tension, maximizing load stability during transit.
The new generation of SBC-932 is equipped with the SSE900 Series cartridge strapping heads, which are engineered and tested to perform in the most demanding working environments. The cartridge concept is ideal to minimize downtime and improve line efficiency.
Bottle & Can Unitizing System Features
Pendant mounted machine controls for access on either side of the machine
Indexing strapping head to ensure tight strap application
Audible out of strap indicator
'Crash-proof' bayonet cylinder prevents damage to bayonet
Three-strand and five-strand chain conveyor and integrated pallet turntable
50+ Years
Design, Manufacturing and Service Experience
End to End
Support and Installation
Purpose-Built
Flexible Solutions
SBC-932 Automatic Side-Seal Strapping Machine
The SBC-932 is ideal for bulk loads of glass bottles, aluminum cans, PET containers and more. There are four compression levels available to provide the best packaging for your application. The heavy duty heater knife has a cycle life in excess of 900,000 cycles, which ensures strong consistent welds and low maintenance. Independent motors, which simplify maintenance and eliminate the need for multiple clutch assemblies, drive the major functions of the SSE-900 Servo Driven Strapping Head.
Additional Options:
Free standing compression units: 500 lbs., 1,200 lbs., or 4,000 lbs.
Strap track underfeed
Multi-strand or roller conveyor with or without turntable
Light beacon alarm system
Power head float for glass applications
SBC-932 Specifications
Specification | |
|---|---|
| Electrical | 460V, 2ph, 60hz |
| : r i A | i s p 0 8 |
| Strap Size | 3/8" (9.5 mm) - 3/8" - 1/2" (9.5 mm - 12.7 mm) |
| Strapping | Polyester |
| Conveyor Height | *Standard - 9" up to 20" |
| Package Sizes | *Standard - Height 26" min. up to 110" max. Width 40" min. up to 60" max. |
Modernize Your Line: Container Strapping System Retrofits
Maximize your capital investment by upgrading your existing equipment with the latest automation, drive technology, and controls.
Performance Upgrades: Retrofit older
Container Systems Control System Modernization: We replace obsolete PLCs and legacy electronics with current-generation automation hardware that delivers enhanced onboard diagnostics, reliable plant-floor integration, and simplified operation where applicable.
Custom Engineering Solutions: Our technical team evaluates your installed equipment and facility layout, then recommends targeted upgrades that avoid the cost and disruption of a full system replacement.
